NEO Series® StorageLoader®



Backup and Archive Made Easy



Download Datasheet

Overview

The NEOs StorageLoader brings easy, affordable high-capacity backup and archive capability to small office environments on a limited budget. Packing up to 240TB in a compact 1u form factor, the NEOs StorageLoader combines ease-of-use features and dependable operation to make efficient, cost-effective offline storage a reality for the most budget-challenged business.

The simplicity of the NEOs StorageLoader also makes it an ideal solution for remote office locations looking to reliably protect important data and move it offsite. If your current data protection strategy involves copying/moving data to a single, desktop tape drive or a tape drive contained in your server, NEOs StorageLoader provides the convenience and reliability of automated data backup, making NEOs StorageLoader the ideal 1st step into automated backup and archive.

With This Product You Can:

  • Affordably backup or archive up to 240TB of data
  • Effortlessly manage your backup and archive processes from anywhere in the world

Request More Overland Storage Information

Our enterprise solution specialists are ready to answer your questions Buy Now

Encryption

NO COPY

Highlights

  • NEOxl 40 can be scaled up to 272 cartridge slots and 21 tape drives, delivering enterprise-class functionality by simply adding up to 6 expansion modules to the base module
  • Flexible expandability and scalability allow you to reconfigure multi-module units and redeploy them as needed

Why You Need It…

  • NO COPY

Remote Management

NEO Series remote management provides intelligent, proactive administration and monitoring of the tape library, tape drives and media, ensuring a seamless backup and archive process.

Highlights

  • 10/100-BaseT Ethernet connection
  • Provides tape drive and tape cartridge status information
  • Enables remote configuration activities
  • Alerts user to unusual/suspicious activity that may affect the backup/archive process via email or SNMP traps
  • Enables remote firmware upgrades
  • Provides remote diagnostics capabilities

Why You Need It…

  • Provides convenience and reliable management of the backup/archive process from anywhere in the world

Removable Cartridge Magazines

NEO Series removable cartridge magazines provide effortless media handling for loading/unloading of cartridges while facilitating off-line storage for disaster recovery purposes.

Highlights

  • Allows users to conveniently add/remove cartridges in their NEO library
  • Provides easy off-line handling of multiple cartridges
  • Enables convenient off-line/off-site storage of cartridges for disaster recovery purpose
  • Ensures more efficient media handling both inside and outside of a NEO Series library

Why You Need It…

  • Reduces administrative overhead by making media handling more efficient and reliable

Comparison

Hardware Specifications NEOs T24 NEOs StorageLoader
# of cartridge slots 24 8
# of mail slots 1 1
# of tape drives 1-2 1
Form factor 2u rackmount 1u rackmount
Tape drive types supported  LTO-6, LTO-7, LTO-8 LTO-6, LTO-7, LTO-8
Interfaces 6Gb SAS, 8Gb FC 6Gb SAS, 8Gb FC
max. # of cartridge slots 24 8
max. # of tape drives 2 1
Max. capacity per module (TB) 360 120
Max. data transfer rate per module (TB/hr.) 5.4 2.7
Dimensions (inches) 3.44″ x 17.6″ x 29.13″ 1.73″ x 18.98″ x 31.85″
Dimensions (mm) 87.4mm x 447.0mm x 739.9mm 43.94mm x 482.1mm x 808.9mm
Weight 33 lbs. / 14.9kg 25.4 lbs. / 11.52kg
Reliability >2,000,000 MCBF (mean cycles between failures); Less than 5 minutes MTTR (mean time to repair) >2,000,000 MCBF (mean cycles between failures); Less than 10 minutes MTTR (mean time to repair)
Power 168 watts 110 watts
Standard Warranty NEO Series libraries include a minimum one-year OverlandCare Bronze Support Coverage,
which includes 5 x 9 telephone support and advanced parts replacement
NEO Series libraries include a minimum one-year OverlandCare Bronze Support Coverage,
which includes 5 x 9 telephone support and advanced parts replacement
